RU1501
Indoor 5G Radio Unit N41

Enhance Industrial Production Efficiency with Industrial 5G Private Networks
pRRU N41

Overview

RU1501 is an indoor 5G radio unit (pRRU) developed by AILINK, based on 3GPP standards, and operating on the N41 (2.6GHz) spectrum. It is designed to meet the functional demands of industrial production environments, providing high reliability, low latency, and substantial bandwidth for extensive device connectivity. The unit supports a variety of installation methods, making it an ideal solution for constructing fully connected 5G smart factories.
  • Support N41 2515-2675MHz
  • 4T4R built-in antenna
  • IP31 -5~＋55℃

Specification parameters

Dimensions (HxWxD)： 206mm x 206mm x 65mm
Weight：2.0 Kg
Frequency band：N41（2515-2675MHz）
Duplex mode：TDD
Antenna：Built-in
Multiplexing：4T4R MIMO (DL: 4L, UL: 4L)
Transmit power：4*400mW
Receive Sensitivity：＜-94 dBm
Interface type：Electrical port 10Gbps x 2 Optical port 25Gbps x1
Power Supply： POE -48V DC
Power Consumption ：60W
Operating temperature：-5℃~＋55℃
Relative humidity： 5% to 95%
Ingress Protection Rating：IP31
